- Working Temperature: -40°C ~ +105°C for industry, -55°C ~ +125°C for military
- Working Frequency: 50 kHz ~ 500 kHz
- Packaging size: 13mmx11.5mmx8.5mm max
- Max current: 20A
- Application: switching power supply
| Current in A | Winding Ratio | Inductance of Secondary in µH | Resistance of Primary in mΩ | Resistance of Secondary in mΩ |
|
20
|
1:50 | 1.4 | 0.5 | 600 |
| 1:70 | 2.8 | 0.5 | 1000 | |
| 1:100 | 5.6 | 0.5 | 2000 | |
| 1:125 | 22.4 | 0.5 | 9000 |
